Kirchhoff's Voltage Law

     Kirchhoff's voltage law states that the algebraic sum of all branch voltages around any closed path in a circuit is always zero at all instants of time. When the current passes though a resistor, there is a loss of energy and, therefore, a voltage drop. In any element, the current always flows from higher potential to lower potential. consider the circuit in fig

It is customary to take the direction of current I as indicate in the figure, i.e. it leaves the positive terminal of the voltage source and enters into the negative terminal.

  As the current passes through the circuit, the sum of the voltage drop around the loop is equal to the total voltage in that loop. Here the polarities are attributed to the resistor to indicate that the voltages at points a, c and e are more than the voltages at b, d and f, respectively, as the current passes from a to f.

   .'.  Vs = V1 +V2+V3

   Consider the problem of finding out the current supplied by the source V in the circuit shown in fig 2

Our first step is to assume the reference current direction and to indicate the polarities for different elements. [See Fig 3].

By using Ohm's law, we find the voltage across each resistor as follows.  Vr1= IR1,Vr3 =IR3

Where Vr1, Vr2 and Vr3 are the voltage across R1, R2 and R3,  respectively. Finally, by applying Kirchhoff's law, we can from the equation

V=Vr1+Vr2+Vr3

V=IR1+IR2+IR3

From the above equation the current delivered by the source is given by   I=V/R1+R2+R3
